NAS server

Gigabit Ethernet / 2.5 Gigabit Ethernet

0 GB

0 (installed) / 8 (max)

32.93 cm

27.96 cm

188.2 cm

7.06 kg ()

Display, 1 x 60 mm CPU fan, 2 x 120 mm fans

1 x Intel Core i5 12400 2.5 GHz

6-core

1

4.4 GHz

32 GB (installed) / 128 GB (supported) - DDR4

5 GB

RAID

SATA 6Gb/s

RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, JBOD, RAID 60, RAID TP

100Mb LAN, GigE, 2.5 GigE

PPTP, L2TP, IPSec, FTP, IPv4, IPv6, Telnet, TFTP, QBelt, OpenVPN

SNMP 2, SNMP 3, RADIUS

Microsoft CIFS, FTP, Server Message Block (SMB), Apple File Protocol (AFP), HTTP, HTTPS, SFTP

Maximum LUN size: 1024 TB Maximum number of targets LUN: 256 Maximum shared folder size: 1024 TB Maximum number of shared folder: 256 Maximum pool size: 1024 TB Maximum number of storage pool: 128 Minimum snapshot interval: 1 minute Maximum FTP connection: 1024 Local user account: 16000 Local group account: 512 Domain user/group account: 200000 Virtual hosts: 32 Maximum number of version control: 64

VLAN support, wake on LAN (WOL), SSH support, Jumbo Frames support, DHCP server, FTP server, Domain Controller, system log, built-in hardware transcoding, file station, port trunking, SSD trim, Windows ODX, FXP support, hybrid backup sync, Qfiling, Qsirch, WORM (Write Once Read Many protection), SQL Server, Network Recycle Bin, VJBOD Cloud, Qsync, QuMagie, Smart Fan, QmailAgent, QuWAN, Shared Folder Snapshot, LDAP server, Storage Pool, SED Storage Pool, JBOD Expansion, Disk, Enclosure Locate, Disk S.M.A.R.T. Scan, Disk S.M.A.R.T. Data Migration, Disk Roaming, Disk Standby, Snapshot Retention Policy, Self-serve Snapshot Recovery, Application Consisted Snapshot, Snapshot Full Clone, Snapshot Replica / Vault, SSD read-only Cache, External Device Management, Mount Smart Phone (MTP), Object Storage, shared folder permission, group quota, folder quota, home folder, Resource Monitor, Virtual Switch, Allow/Deny List, Access Protection, Service binding, HD Station, DA Driver Analyzer, floating point unit, SSD cache ac

TLS 1.0, FIPS 140-2, 256-bit AES, TLS 1.1, TLS 1.2, AES-NI, TLS 1.3

8 (total) / 8 (free) x hot-swap - 2.5" / 3.5"

2 (total) / 2 (free) x M.2 2280 1 (total) / 1 (free) x PCI Express 4.0 x16 1 (total) / 1 (free) x PCI Express 4.0 x4

2 x USB 3.2 Gen 2 - Type A 2 x 2.5 Gigabit Ethernet - RJ-45 1 x USB 3.2 Gen 2 - Type C 1 x HDMI output

1 x network cable

Security lock slot (cable lock sold separately)

Kensington security slot

2 x M.2 SSD heatsink, 24 x flat head screws (for 2.5" HDD), 32 x flat head screws (for 3.5" HDD), 2 x drive tray keys

Internal power supply

1

AC 100-240 V

85.701 Watt

250 Watt

QNAP QuTS hero h5.0.0

Microsoft Windows Server 2008 R2, IBM AIX 7, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Ubuntu 14.04, Red Hat Enterprise Linux 6.6, Microsoft Windows Server 2016, Apple MacOS X 10.10 or later, CentOS 7.0, Microsoft Windows Server 2019, SuSE Linux 12 or later, Oracle Solaris 10 or later, Microsoft Windows 7 / 8 / 10 / 11

Limited warranty - 3 years

9.19 kg

0 °C

40 °C

5 - 95% (non-condensing)
