Intel S3520 Enterprise Entry - Solid state drive - 240 GB - hot-swap - 2.5" - SATA 6Gb / s - for ThinkSystem SD530; SN850; SR530; SR550; SR570; SR590; SR650; SR850; SR860; SR950; ST550
Intel S3520 Enterprise Entry - Solid state drive - 240 GB - hot-swap - 2.5" - SATA 6Gb / s - for ThinkSystem SD530; SN850; SR530; SR550; SR570; SR590; SR650; SR850; SR860; SR950; ST550
Ražotājs
•LENOVO
Ražotāja kods
•7N47A00099
Artikuls
•1491991
Intrastat
•84717050
Pakas svars
•0.066 kg
Device Type
Solid state drive - hot-swap
Capacity
240 GB
NAND Flash Memory Type
3D multi-level cell (MLC)
Form Factor
2.5"
Interface
SATA 6Gb/s
Features
Enhanced Power Loss Data Protection, Thermal throttling, End-to-end data path protection, End-to-end data protection, Standard Endurance Technology (SET), S.M.A.R.T., 256-bit AES
Width
70 mm
Depth
100 mm
Height
7 mm
Weight
66 g
Drive Writes Per Day (DWPD)
1.4
SSD Endurance
599 TB
Drive Transfer Rate
600 MBps (external)
Internal Data Rate
450 MBps (read) / 380 MBps (write)
4KB Random Read
67500 IOPS
4KB Random Write
17000 IOPS
Average Latency
40 µs
MTBF
2,000,000 hours
Non-Recoverable Errors
1 per 10^17
Interfaces
1 x SATA 6 Gb/s
Compatible Bay
2.5"
Power Consumption
3.5 Watt (typical)
OS Required
Microsoft Windows Server 2008 R2, SuSE Linux Enterprise Server 11 for x86/AMD64/Intel EM64T, SuSE Linux Enterprise Server 10 for x86/AMD64/Intel EM64T, Microsoft Windows Server 2008 Standard, Microsoft Windows Web Server 2008, Microsoft Windows Server 2008 Datacenter x64 Edition, Microsoft Windows Server 2008 Enterprise x64 Edition, Microsoft Windows Server 2008 Standard x64 Edition, Red Hat Linux Enterprise Server 5, VMware ESX 4.1, VMware ESXi 4.1, Red Hat Linux Enterprise Server 5 x64 Edition, Red Hat Linux Enterprise Server 6 x64 Edition, Microsoft Windows Web Server 2008 x64 Edition, Red Hat Linux Enterprise Server 6, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Red Hat Enterprise Linux 5 Server with Xen x64 Edition, SUSE LINUX Enterprise Server 11 with Xen for AMD64/EM64T, VMware vSphere 5.5 (ESXi), VMware vSphere 5.0 (ESXi), Microsoft Windows Server 2008 Datacenter x86 Edition, Microsoft Windows Server 2008 Enterprise x86 Edition, Microsoft Windows Server 2016, Red Hat Linux Enterpr
Compliant Standards
EN55022, KCC, BSMI CNS 13438, EN 60950-1 Second Edition, Directive 2006/95/EC, RoHS 2011/65/EU, EN55022:2006, WEEE 2002/96/EC, EN55024:1998, CAN/CSA-CEI/IEC CISPR 22:02, FCC CFR47 Part 15 B Class B, UL/CSA60950-1
Service & Support
Limited warranty - replacement - 1 year
Min Operating Temperature
0 °C
Max Operating Temperature
70 °C
Humidity Range Operating
5 - 95% (non-condensing)
Shock Tolerance (operating)
1000 g @ 0.5 ms
Vibration Tolerance (operating)
2.17 g @ 5-700 Hz
Vibration Tolerance (non-operating)
3.13 g @ 5-700 Hz
Designed For
Lenovo ThinkSystem SD530 (2.5") ¦ Lenovo ThinkSystem SN550 (2.5") ¦ Lenovo ThinkSystem SN850 (2.5") ¦ Lenovo ThinkSystem SR530 (2.5") ¦ Lenovo ThinkSystem SR550 (2.5") ¦ Lenovo ThinkSystem SR570 (2.5") ¦ Lenovo ThinkSystem SR590 (2.5") ¦ Lenovo ThinkSystem SR630 (2.5") ¦ Lenovo ThinkSystem SR650 (2.5") ¦ Lenovo ThinkSystem SR850 (2.5") ¦ Lenovo ThinkSystem SR860 (2.5") ¦ Lenovo ThinkSystem SR950 (2.5") ¦ Lenovo ThinkSystem ST550 (2.5")
