Extreme Networks Extreme Management Center NMS-A-25 - Network management device - GigE - 1U - rack-mountable
images are for illustrative purposes only
| Device Type | Network management device |
| Height (Rack Units) | 1U |
| Width | 43 cm |
| Depth | 70.99 cm |
| Height | 4.45 cm |
| Weight | 13.15 kg |
| Processors Installed | 1 x Intel Xeon E5-2620V4 2.1 GHz |
| RAM | 32 GB (48 GB max) DDR4 SDRAM DIMM 288-pin |
| Hard Drive | SSD 480 GB x 1 |
| Form Factor | Rack-mountable |
| Connectivity Technology | Wired |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Capacity | Maximum number of access points: 12500 ¦ Maximum number of wireless MUs: 50000 ¦ Maximum number of managed devices: 5000 ¦ Access control end-system: 100000 ¦ Static retention: 180 days |
| Status Indicators | Port transmission speed, power, system, HDD activity, status, link/activity, management |
| Features | Trusted Platform Module 2.0 (TPM 2.0) |
| Expansion Bays | 4 external |
| Expansion Slots | DIMM 288-pin ¦ 2 (total) / 2 (free) x expansion slot |
| Interfaces | 4 x network - RJ-45 ¦ 1 x serial - DB-9 ¦ 3 x USB 2.0 - Type A ¦ 2 x VGA - HD-15 ¦ 2 x 1000Base-T - RJ-45 ¦ 2 x USB 3.0 - Type A |
| Compliant Standards | ASHRAE Class A4, ASHRAE Class A3, ASHRAE Class A2 |
| Power Device | Internal power supply - hot-plug |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Power Redundancy | Yes |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Provided | 750 Watt |
| 80 PLUS Certification | 80 PLUS Platinum |
| Service & Support | Limited warranty - parts and labour - 1 year |
| Min Operating Temperature | 10 °C |
| Max Operating Temperature | 35 °C |
