HPE ProLiant DL325 Gen10 Plus - Server - rack-mountable - 1U - 1-way - 1 x EPYC 7262 / 3.2 GHz - RAM 16 GB - SAS - hot-swap 3.5" bay(s) - no HDD - GigE - monitor: none
images are for illustrative purposes only
New
Article: 1808253 SKU: P18603-B21
Pricing and stock details are available to registered users only.
| Type | Server |
| Product Form Factor | Rack-mountable - 1U |
| Server Scalability | 1-way |
| Hot-Swap Bays Qty | 4 |
| Localisation | Region: Worldwide |
| CPU | AMD EPYC 7262 / 3.2 GHz |
| Max Turbo Speed | 3.4 GHz |
| Number of Cores | 8-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| CPU Upgradability | Upgradable |
| CPU Socket | Socket SP3 |
| Installed Size | 128 MB |
| Cache Per Processor | 128 MB |
| Installed Size | 16 GB / 1 TB (max) |
| Technology | DDR4 SDRAM |
| Rated Memory Speed | 3200 MHz |
| Form Factor | DIMM 288-pin |
| Slots | 16 (Total) / 15 (empty) |
| Features | Registered, HPE SmartMemory |
| Configuration Features | 1 x 16 GB |
| RAM Supported | PC4-20800 - 2 TB Load-Reduced PC4-20800 - 1 TB registered |
| Type | No HDD |
| Type | RAID - PCIe 3.0 x8 |
| Controller Interface Type | SATA 6Gb/s / SAS 12Gb/s |
| Storage Controller Name | HPE Smart Array E208i-a |
| Type | No optical drive |
| Monitor Type | None. |
| Video Memory | 16 MB |
| Video Interfaces | VGA |
| Ethernet Ports | 4 x Gigabit Ethernet |
| Ethernet Controller | Intel I350-T4 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Controller | Integrated Lights-Out 5 |
| Features | Wake on LAN (WoL), PXE support |
| Bays | 4 (total) / 4 (free) x hot-swap 3.5" LFF |
| Slots | 1 (total) / 1 (free) x FlexibleLOM 1 (total) / 1 (free) x PCIe 3.0 x16 1 (total) / 1 (free) x PCIe 3.0 x8 1 (total) / 1 (free) x microSD Card (internal) |
| Interfaces | 1 x HPE iLO (1 in front) 5 x USB 3.0 4 x LAN (Gigabit Ethernet) 1 x HPE iLO 1 x VGA |
| Included Accessories | HPE Easy Install Rails, 6 x standard fans |
| Compliant Standards | AES, FIPS 140-2, Triple DES, IPv6 Ready, PCI DSS, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1 |
| Device Type | Power supply - hot-plug |
| Power Redundancy | Optional |
| Power Redundancy Scheme | 1+1 (with optional power supply) |
| Installed Qty | 1 |
| Max Supported Qty | 2 |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Provided | 500 Watt |
| ENERGY STAR Certified | Yes |
| ENERGY STAR Version | 3.0 |
| Service & Support | Limited warranty - parts and labour - 3 years - on-site |
| Width | 43.46 cm |
| Depth | 82.62 cm |
| Height | 4.28 cm |
| Weight | 17 kg |
| Min Operating Temperature | 10 °C |
| Max Operating Temperature | 35 °C |
| Humidity Range Operating | 8 - 90% (non-condensing) |
