HPE ProLiant DL380 Gen10 Network Choice - Server - rack-mountable - 2U - 2-way - 1 x Xeon Gold 5218 / 2.3 GHz - RAM 32 GB - SATA / SAS / NVMe - hot-swap 2.5" bay(s) - no HDD - 10 GigE - monitor: none - BTO
HPE ProLiant DL380 Gen10 Network Choice - Server - rack-mountable - 2U - 2-way - 1 x Xeon Gold 5218 / 2.3 GHz - RAM 32 GB - SATA / SAS / NVMe - hot-swap 2.5" bay(s) - no HDD - 10 GigE - monitor: none - BTO
Manufacturer
•HPE
Reference
•P56962-B21
Article
•3134552
Shipping weight
•14.76 kg
Type
Server
Product Form Factor
Rack-mountable - 2U
Built-in Devices
Led panel
Server Scalability
2-way
Hot-Swap Bays Qty
8
Localisation
Region: Worldwide
CPU
Intel Xeon Gold 5218
Clock Speed
2.3 GHz
Max Turbo Speed
3.9 GHz
Number of Cores
16-core
CPU Qty
1
Max CPU Qty
2
CPU Upgradability
Upgradable
Processor Main Features
Hyper-Threading Technology, Intel Turbo Boost Technology 2
Chipset Type
Intel C621
Installed Size
L3 Cache - 22 MB
Cache Per Processor
22 MB
Installed Size
32 GB / 3 TB (max)
Technology
DDR4 SDRAM
Effective Memory Speed
2400 MHz
Rated Memory Speed
2933 MHz
Memory Specification Compliance
PC4-23466
Form Factor
DIMM 288-pin
Slots
24 (Total) / 23 (empty)
Configuration Features
1 x 32 GB
RAM Supported
3 TB Load-Reduced - ECC ¦ 1.5 TB registered - ECC ¦ 192 GB Non-Volatile - ECC
Type
No HDD
Type
1 x RAID
Controller Interface Type
SAS 12Gb/s
Storage Controller Name
Broadcom MegaRAID MR416i-a
Buffer Size
4 GB
Type
No optical drive
Type
Card reader
Supported Flash Memory Cards
microSD
Monitor Type
None.
Video Memory
16 MB
Video Interfaces
VGA
Ethernet Ports
2 x 10 Gigabit Ethernet
Ethernet Controller
Broadcom BCM57414
Data Link Protocol
10 Gigabit Ethernet
Remote Management Protocol
SNMP 3, IPMI 2.0, SMASH CLP
Remote Management Controller
Integrated Lights-Out 5
Features
Wake on LAN (WoL), PXE support
Bays
1 (total) / 1 (free) x external Universal Media Bay ¦ 8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots
1 (total) / 1 (free) x FlexibleLOM ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - half-length, full-height ¦ 2 (total) / 2 (free) x PCIe 3.0 x8 - half-length, full-height ¦ 1 (total) / 1 (free) x microSD Card (internal)
Interfaces
1 x HPE iLO - Type A (1 in front) ¦ 5 x USB 3.0 (1 front, 2 rear, 2 internal) ¦ 1 x HPE iLO - RJ-45 (1 rear) ¦ 2 x LAN (10Gigabit Ethernet) - SFP28 (2 rear) ¦ 1 x VGA (1 rear)
Included Accessories
4 standard fans, CPU standard heatsink, HPE Easy Install Rails with CMA
Compliant Standards
AES, FIPS 140-2, WEEE, Triple DES, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, Redfish API, UEFI, ACPI 6.3, SMBIOS 3.2
Pricing Type
BTO
Device Type
Power supply - hot-plug
Power Redundancy
Optional
Power Redundancy Scheme
1+1 (with optional power supply)
Installed Qty
1
Max Supported Qty
2
Voltage Required
AC 100-240 V (50/60 Hz)
Power Provided
800 Watt
80 PLUS Certification
80 PLUS Platinum
Software
HPE Server UEFI
ENERGY STAR Certified
Yes
ENERGY STAR Version
3.0
Service & Support
Limited warranty - parts and labour - 3 years - response time: next business day
Width
44.55 cm
Depth
73.03 cm
Height
8.74 cm
Weight
14.76 kg
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
