HPE ProLiant DL380 Gen10 SMB Networking Choice - Server - rack-mountable - 2U - 2-way - 1 x Xeon Gold 5218R / 2.1 GHz - RAM 32 GB - SATA - hot-swap 2.5" bay(s) - no HDD - 10 GigE - monitor: none
HPE ProLiant DL380 Gen10 SMB Networking Choice - Server - rack-mountable - 2U - 2-way - 1 x Xeon Gold 5218R / 2.1 GHz - RAM 32 GB - SATA - hot-swap 2.5" bay(s) - no HDD - 10 GigE - monitor: none
Manufacturer
•HPE
Reference
•P36135-B21
Article
•1808248
Shipping weight
•23.3 kg
Type
Server
Product Form Factor
Rack-mountable - 2U
Server Scalability
2-way
Hot-Swap Bays Qty
8
Localisation
Region: Worldwide
CPU
Intel Xeon Gold 5218R / 2.1 GHz
Max Turbo Speed
4 GHz
Number of Cores
20-core
CPU Qty
1
Max CPU Qty
2
CPU Upgradability
Upgradable
Processor Main Features
Hyper-Threading Technology, Intel Turbo Boost Technology 2
CPU Socket
FCLGA3647 Socket
Chipset Type
Intel C621
Installed Size
L3 Cache - 27.5 MB
Cache Per Processor
27.5 MB
Installed Size
32 GB / 1.5 TB (max)
Technology
DDR4 SDRAM - Advanced ECC
Effective Memory Speed
2666 MHz
Rated Memory Speed
2933 MHz
Form Factor
DIMM 288-pin
Slots
24 (Total) / 23 (empty)
Features
Registered, dual rank, slots 13 - 24 are available in two-processor configuration only, HPE SmartMemory
Configuration Features
1 x 32 GB
RAM Supported
3 TB Load-Reduced - ECC
1.5 TB registered - ECC
192 GB Non-Volatile - ECC
6 TB - HPE Persistent Memory - Optane DC Persistent
Type
No HDD
Type
1 x RAID
Controller Interface Type
SATA 6Gb/s
Storage Controller Name
HPE Smart Array S100i
Channel Qty
14
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10
Type
No optical drive
Monitor Type
None.
Video Memory
16 MB
Video Interfaces
VGA
Ethernet Ports
2 x 10 Gigabit Ethernet
Ethernet Controller
Broadcom BCM57416
Data Link Protocol
10 Gigabit Ethernet
Remote Management Controller
Integrated Lights-Out 5
Features
Wake on LAN (WoL), PXE support
Bays
8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots
1 (total) / 1 (free) x microSD Card (internal)
1 (total) / 1 (free) x PCIe 3.0 x8 - full-length, full-height
1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height
1 (total) / 1 (free) x PCIe 3.0 x8 - half-length, full-height
1 (total) / 0 (free) x FlexibleLOM
Interfaces
3 x USB 3.0 (1 front, 2 rear)
1 x VGA
2 x LAN (10Gigabit Ethernet)
1 x HPE iLO
1 x HPE iLO (service port)
Included Accessories
Cable management arm, 4 standard fans, SFF Easy install rails
Compliant Standards
WEEE, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1
Device Type
Power supply - hot-plug
Power Redundancy
Optional
Power Redundancy Scheme
1+1 (with optional power supply)
Installed Qty
1
Max Supported Qty
2
Voltage Required
AC 120/230 V (50/60 Hz)
Power Provided
800 Watt
Software
HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download)
ENERGY STAR Certified
Yes
ENERGY STAR Version
3.0
Service & Support
Limited warranty - parts and labour - 3 years - on-site
Width
44.55 cm
Depth
73.03 cm
Height
8.74 cm
Weight
14.76 kg
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
