HPE ProLiant MicroServer Gen10 Plus Performance - Server - ultra micro tower - 1-way - 1 x Xeon E-2224 / 3.4 GHz - RAM 16 GB - SATA - non-hot-swap 3.5" bay(s) - no HDD - no graphics - GigE - no OS - monitor: none
images are for illustrative purposes only
New
Article: 1690112 SKU: P16006-421
Pricing and stock details are available to registered users only.
| Type | Server |
| Product Form Factor | Ultra micro tower |
| Server Scalability | 1-way |
| Internal Bays Qty | 4 |
| Localisation | Region: EMEA |
| CPU | Intel Xeon E-2224 |
| Clock Speed | 3.4 GHz |
| Max Turbo Speed | 4.6 GHz |
| Number of Cores | Quad-Core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| CPU Upgradability | Upgradable |
| Processor Main Features | Intel Turbo Boost Technology 2, Intel Smart Cache |
| CPU Socket | LGA1151 Socket |
| Chipset Type | Intel C242 |
| Installed Size | 8 MB |
| Cache Per Processor | 8 MB |
| Installed Size | 16 GB / 32 GB (max) |
| Technology | DDR4 SDRAM - ECC |
| Effective Memory Speed | 2666 MHz |
| Rated Memory Speed | 2666 MHz |
| Memory Specification Compliance | PC4-21333 |
| Form Factor | DIMM 288-pin |
| Slots | 2 (Total) / 1 (empty) |
| Features | Unbuffered |
| Configuration Features | 1 x 16 GB |
| Type | No HDD |
| Type | 1 x RAID - PCIe 3.0 x4 |
| Controller Interface Type | SATA 6Gb/s |
| Storage Controller Name | HPE Smart Array S100i SR Software RAID |
| Channel Qty | 14 |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 10 |
| Type | No optical drive |
| Monitor Type | None. |
| Graphics Processor | No graphics |
| Video Interfaces | VGA, DisplayPort |
| Ethernet Ports | 4 x Gigabit Ethernet |
| Ethernet Controller | Intel I350-AM4 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol | SNMP 3, IPMI 2.0, SMASH CLP |
| Features | Wake on LAN (WoL), ACPI support, PXE support |
| Bays | 4 (total) / 4 (free) x internal 3.5" LFF |
| Slots | 1 (total) / 1 (free) x PCIe 3.0 x16 - low-profile ¦ 1 (total) / 1 (free) x expansion slot (iLO Enablement Kit slot) |
| Interfaces | 1 x VGA ¦ 1 x DisplayPort ¦ 4 x USB 3.2 Gen 1 ¦ 2 x USB 3.2 Gen 2 (2 in front) ¦ 4 x LAN (Gigabit Ethernet) |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately), padlock loop |
| Security Slot Type | Kensington security slot |
| Compliant Standards | FCC Class B certified, EN 61000-3-2, ICES-003, EN 61000-3-3, EN55024, AES, FCC CFR47 Part 15, Triple DES, EMC Class B, GB 9254, CNS 13438, TLS v1.2, K24, CISPR 32, EN 55032, K32, ASHRAE Class A2, Redfish API, UEFI |
| Device Type | Power adapter |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Provided | 180 Watt |
| OS Provided | No operating system |
| OS Certified | Microsoft Windows Server 2016, ClearOS, Red Hat Enterprise Linux 8.0, Microsoft Windows Server 2019, VMware ESXi 6.5 update 3, VMware ESXi 6.7 update 3, Red Hat Enterprise Linux 7.6, Red Hat Enterprise Linux 8.1, Red Hat Enterprise Linux 7.7 |
| Service & Support | Limited warranty - parts and labour - 1 year - on-site - response time: next business day |
| Width | 24.5 cm |
| Depth | 24.5 cm |
| Height | 11.89 cm |
| Weight | 4.23 kg |
| Min Operating Temperature | 10 °C |
| Max Operating Temperature | 35 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Sound Emission | 21 dBA |
