HPE ProLiant MicroServer Gen10 Plus Performance - Server - ultra micro tower - 1-way - 1 x Xeon E-2224 / 3.4 GHz - RAM 16 GB - SATA - non-hot-swap 3.5" bay(s) - no HDD - no graphics - GigE - no OS - monitor: none
HPE ProLiant MicroServer Gen10 Plus Performance - Server - ultra micro tower - 1-way - 1 x Xeon E-2224 / 3.4 GHz - RAM 16 GB - SATA - non-hot-swap 3.5" bay(s) - no HDD - no graphics - GigE - no OS - monitor: none
Manufacturer
•HPE
Reference
•P16006-421
Article
•1690112
Shipping weight
•6.755 kg
Type
Server
Product Form Factor
Ultra micro tower
Server Scalability
1-way
Internal Bays Qty
4
Localisation
Region: EMEA
CPU
Intel Xeon E-2224
Clock Speed
3.4 GHz
Max Turbo Speed
4.6 GHz
Number of Cores
Quad-Core
CPU Qty
1
Max CPU Qty
1
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology 2, Intel Smart Cache
CPU Socket
LGA1151 Socket
Chipset Type
Intel C242
Installed Size
8 MB
Cache Per Processor
8 MB
Installed Size
16 GB / 32 GB (max)
Technology
DDR4 SDRAM - ECC
Effective Memory Speed
2666 MHz
Rated Memory Speed
2666 MHz
Memory Specification Compliance
PC4-21333
Form Factor
DIMM 288-pin
Slots
2 (Total) / 1 (empty)
Features
Unbuffered
Configuration Features
1 x 16 GB
Type
No HDD
Type
1 x RAID - PCIe 3.0 x4
Controller Interface Type
SATA 6Gb/s
Storage Controller Name
HPE Smart Array S100i SR Software RAID
Channel Qty
14
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10
Type
No optical drive
Monitor Type
None.
Graphics Processor
No graphics
Video Interfaces
VGA, DisplayPort
Ethernet Ports
4 x Gigabit Ethernet
Ethernet Controller
Intel I350-AM4
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
SNMP 3, IPMI 2.0, SMASH CLP
Features
Wake on LAN (WoL), ACPI support, PXE support
Bays
4 (total) / 4 (free) x internal 3.5" LFF
Slots
1 (total) / 1 (free) x PCIe 3.0 x16 - low-profile ¦ 1 (total) / 1 (free) x expansion slot (iLO Enablement Kit slot)
Interfaces
1 x VGA ¦ 1 x DisplayPort ¦ 4 x USB 3.2 Gen 1 ¦ 2 x USB 3.2 Gen 2 (2 in front) ¦ 4 x LAN (Gigabit Ethernet)
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), padlock loop
Security Slot Type
Kensington security slot
Compliant Standards
FCC Class B certified, EN 61000-3-2, ICES-003, EN 61000-3-3, EN55024, AES, FCC CFR47 Part 15, Triple DES, EMC Class B, GB 9254, CNS 13438, TLS v1.2, K24, CISPR 32, EN 55032, K32, ASHRAE Class A2, Redfish API, UEFI
Device Type
Power adapter
Voltage Required
AC 120/230 V (50/60 Hz)
Power Provided
180 Watt
OS Provided
No operating system
OS Certified
Microsoft Windows Server 2016, ClearOS, Red Hat Enterprise Linux 8.0, Microsoft Windows Server 2019, VMware ESXi 6.5 update 3, VMware ESXi 6.7 update 3, Red Hat Enterprise Linux 7.6, Red Hat Enterprise Linux 8.1, Red Hat Enterprise Linux 7.7
Service & Support
Limited warranty - parts and labour - 1 year - on-site - response time: next business day
Width
24.5 cm
Depth
24.5 cm
Height
11.89 cm
Weight
4.23 kg
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
10 - 90% (non-condensing)
Sound Emission
21 dBA
