Datalogic Gryphon I GD4520 - High Density (HD) - Kit - barcode scanner - 2D imager - decoded - USB
images are for illustrative purposes only
New
Article: 1738758 Intrastat: 84716070 SKU: GD4520-BKK1-HD-DRA
Pricing and stock details are available to registered users only.
| Type | Barcode scanner |
| Colour | Black |
| Interface Type | USB |
| Scan Element Type | 2D imager |
| Sensor Resolution | 1280 x 800 |
| Light Source Wave Length | 650 nm |
| Skew (Degrees) | 65 |
| Pitch (Degrees) | 65 |
| Print Contrast Signal (PCS) | 15% |
| Decode Capability | MaxiCode, Aztec code, MicroPDF417, Postnet, PDF417, Data Matrix, PLANET, Australian Post, British Post, China Post, Japanese Post, Kix (Netherlands) Post, MacroPDF417, RM4SCC, Royal Mail, Micro QR code, GS1 DataBar Stacked Omnidirectional, GS1 DataBar Expanded Stacked, GS1 DataBar Composites, GS1 DataBar Stacked, China Han Xin Code, UPC A Composite, UPC E Composite |
| TTL Decoding | Decoded |
| Connectivity Technology | Wired |
| OK Notification | Beeper, LED indicator |
| Features | Antimicrobial protection, Datalogic Three Green Lights (3GL), Green Spot technology, disinfectant ready housing, Digimarc Barcode Technology, Direct Part Mark (DPM) |
| Interfaces | 1 x USB |
| Cables Included | 1 x USB cable - 2 m |
| Compliant Standards | RoHS, IP52 |
| Width | 6.8 cm |
| Depth | 10.9 cm |
| Height | 16.6 cm |
| Weight | 161 g |
| Service & Support | Limited warranty - 5 years |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 0 - 95% (non-condensing) |
| Drop Specification | 1.8 m to concrete |
