Symbol LS1203 - Barcode scanner - handheld - 100 scan / sec - decoded - keyboard wedge, USB
images are for illustrative purposes only
New
Article: 79084 Intrastat: 84716070 SKU: LS1203-CR10007R
Pricing and stock details are available to registered users only.
| Type | Barcode scanner - handheld |
| Colour | Twilight black |
| Interface Type | Keyboard wedge, USB |
| Minimum Bar Width | 5 mil |
| Scan Element Type | Visible laser diode |
| Light Source Wave Length | 650 nm |
| Scan Mode | Single-pass |
| Scan Speed | 100 scan / sec |
| Max Working Distance | 20.3 cm |
| Skew (Degrees) | 60 |
| Pitch (Degrees) | 65 |
| Print Contrast Signal (PCS) | 30% |
| Decode Capability | Code 93, Code 39, UCC/EAN-128, IATA, GS1 DataBar, Code 39 Full ASCII, Discrete 2 of 5, Codabar, Code 128, Code 11, UPC, Interleaved 2 of 5, Code 128 Full ASCII, Code 39 Trioptic |
| TTL Decoding | Decoded |
| Connectivity Technology | Wired |
| OK Notification | Beeper |
| Interfaces | 1 x USB ¦ 1 x keyboard wedge |
| Compliant Standards | VCCI, EN 60950, IEC950, UL 1950, ICES-003 Class B, FCC Part 15 B, MITI, EMC, CSA C22.2 No. 950 |
| Width | 6 cm |
| Depth | 18 cm |
| Height | 6.2 cm |
| Weight | 122 g |
| Service & Support | Limited warranty - 3 years |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 5 - 95% |
| Drop Specification | 1.5 m to concrete |
