Datalogic Gryphon GFS4550 - Barcode scanner - desktop - 2D imager - 60 frames / sec - decoded - RS-232
Manufacturer
•DATALOGIC
Reference
•GFS4550-BKK2-RED
Article
•3188822
Intrastat
•84719000
Shipping weight
•0.152 kg
Total quantity in stocks
•500
Nearest delivery
•13.11.2026
Manufacturer price
•453.00 €
2DSerial port
Built-in scanner, 2D, imager (1 MP, wide angle, illumination: red), RS232, incl.: cable (RS232), IP54, black
Type
Barcode scanner - desktop
Colour
Black
Interface Type
RS-232
Minimum Bar Width
3 mil
Scan Field Width
15 mm - 82 cm
Scan Element Type
2D imager - LED
Sensor Resolution
1280 x 800
Frame Rate
60 frames / sec
Skew (Degrees)
60
Pitch (Degrees)
60
Print Contrast Signal (PCS)
15%
Decode Capability
GS1 DataBar, Aztec code, China Han Xin Code, Data Matrix, MaxiCode, Micro QR code, QR code, DotCode, Dotted DataMatrix, Australian Post, British Post, China Post, Japanese Post, IMB, Kix (Netherlands) Post, PLANET, Royal Mail, Postnet, EAN/JAN, GS1 DataBar Composites, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, MacroPDF417, PDF417, UPC-A, UPC-E, Digimarc Barcode, MicroPDF417
TTL Decoding
Decoded
Connectivity Technology
Wired
OK Notification
Beeper, LED indicator
Features
Red LEDs illumination, drop protection
Interfaces
1 x digital input ¦ 1 x RS-232 - DB-9 ¦ 1 x digital output
Cables Included
1 x serial cable - external - 2 m
Compliant Standards
IP54, China RoHS, EU RoHS, IEC 62471
Voltage
DC 5 - 14 V
Electric Current Required
225 mA (operating)
Software Included
Datalogic Aladdin, OPOS/JavaPOS Drivers
Width
5.5 cm
Depth
4.8 cm
Height
2.8 cm
Weight
152 g
Service & Support
Limited warranty - 5 years
Min Operating Temperature
-20 °C
Max Operating Temperature
50 °C
Drop Specification
1.5 m to concrete
