Gigabyte BRIX Extreme GB-BEi7-1260 (rev. 1.0) - Barebone - mini PC - 1 x Core i7 1260P / 2.1 GHz - RAM 0 GB - Intel Iris Xe Graphics - Gigabit Ethernet, 2.5 Gigabit Ethernet, Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6E) WLAN: - Bluetooth 5.2, 802.11a / b / g / n / ac / ax (Wi-Fi 6E)
images are for illustrative purposes only
New
Article: 3036556 Intrastat: 84718000 SKU: GB-BEI7-1260
Pricing and stock details are available to registered users only.
| Type | PC barebone |
| Product Form Factor | Mini PC |
| CPU | Intel Core i7 (12th Gen) 1260P |
| Clock Speed | 2.1 GHz (P-core) / 1.5 GHz (E-core) |
| Max Turbo Speed | 4.7 GHz (P-core) / 3.4 GHz (E-core) |
| Number of Cores | 12-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Processor Main Features | Intel Smart Cache |
| Installed Size | L3 Cache - 18 MB |
| Cache Per Processor | 18 MB |
| Installed Size | 0 GB / 64 GB (max) |
| Technology | DDR4 SDRAM |
| Effective Memory Speed | 3200 MHz |
| Rated Memory Speed | 3200 MHz |
| Form Factor | SO-DIMM 260-pin |
| Slots | 2 (Total) / 2 (empty) |
| Type | No HDD |
| Type | No optical drive |
| Monitor Type | None. |
| Graphics Processor | Intel Iris Xe Graphics |
| Max Monitors Supported | 4 |
| Sound Output Mode | Stereo |
| Compliant Standards | High Definition Audio |
| Ethernet Controller | Intel i225 |
| Wireless LAN Supported | Yes |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6E) |
| Slots | 1 (total) / 1 (free) x M.2 Card - 2280 (PCIe 4.0 x4 mode) ¦ 1 (total) / 0 (free) x M.2 Card - 2230 (for wireless module) |
| Interfaces | 1 x USB-C 3.2 Gen 2 (1 front) ¦ 3 x USB 3.2 Gen 2 (3 in front) ¦ 1 x headphones/microphone - mini-jack (1 front) ¦ 2 x HDMI (2 rear) ¦ 1 x Mini DisplayPort (1 rear) ¦ 1 x Thunderbolt 4/DisplayPort/USB-C (1 rear) ¦ 2 x USB 2.0 (2 rear) ¦ 1 x LAN (2.5Gigabit Ethernet) (1 rear) |
| Included Accessories | VESA bracket |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington security slot |
| VESA Mounting Interface | 100 x 100 mm, 75 x 75 mm |
| Device Type | Power adapter |
| Voltage Required | AC 100-240 V |
| Power Provided | 135 Watt |
| OS Provided | No operating system |
| OS Certified | Windows 10, Windows 11 |
| Width | 13.42 cm |
| Depth | 13.91 cm |
| Height | 4.83 cm |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 35 °C |
