Gigabyte BRIX s GB-BRR7H-4800 (rev. 1.0) - Barebone - Ultra Compact PC Kit - 1 x Ryzen 7 4800U / 1.8 GHz - RAM 0 GB - Radeon Graphics - 2.5 GigE, Bluetooth 5.2 - WLAN: 802.11a/b/g/n/ac/ax, Bluetooth 5.2
New
Article: 1864578 Intrastat: 84718000 SKU: GB-BRR7H-4800
Pricing and stock details are available to registered users only.
| Type | PC barebone |
| Product Form Factor | Ultra Compact PC Kit |
| CPU | AMD Ryzen 7 4800U |
| Clock Speed | 1.8 GHz |
| Max Turbo Speed | 4.2 GHz |
| Number of Cores | 8-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Installed Size | L3 Cache - 8 MB |
| Cache Per Processor | 8 MB |
| Installed Size | 0 GB / 64 GB (max) |
| Technology | DDR4 SDRAM |
| Form Factor | SO-DIMM 260-pin |
| Slots | 2 (Total) / 2 (empty) |
| Type | No HDD |
| Type | 1 x SATA |
| Controller Interface Type | SATA 6Gb/s |
| Channel Qty | 1 |
| Type | No optical drive |
| Monitor Type | None. |
| Graphics Processor | AMD Radeon Graphics |
| Video Interfaces | HDMI, DisplayPort, USB-C |
| Max Monitors Supported | 4 |
| Wireless LAN Supported | Yes |
| Wireless NIC | Intel Wi-Fi 6 AX 200 |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.2 |
| Bays | 1 (total) / 1 (free) x internal 2.5" |
| Slots | 1 (total) / 0 (free) x M.2 Card - 2230 (Key A-E) 1 (total) / 1 (free) x M.2 Card - 2280 |
| Interfaces | 5 x USB 3.2 Gen 1 (3 front, 2 rear) 1 x HDMI 1 x Mini DisplayPort 1 x LAN (2.5Gigabit Ethernet) 1 x headphones/microphone (1 in front) 2 x DisplayPort/USB-C 3.2 Gen 2 (1 front, 1 rear) 1 x serial |
| Included Accessories | VESA wallmount adapter |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington security slot |
| VESA Mounting Interface | 100 x 100 mm, 75 x 75 mm |
| Compliant Standards | HDCP 2.2 |
| Device Type | Power adapter |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Provided | 90 Watt |
| OS Provided | No operating system |
| Width | 11.95 cm |
| Depth | 11.95 cm |
| Height | 4.68 cm |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 35 °C |
