Intel Next Unit of Computing 11 Extreme Kit - NUC11BTMi7 - Barebone - mini PC - Intel WM590 - 1 x Core i7 11700B / 3.2 GHz - RAM 0 GB - UHD Graphics - GigE, 2.5 GigE, Bluetooth 5.2 - WLAN: 802.11a / b / g / n / ac / ax, Bluetooth 5.2
images are for illustrative purposes only
New
Article: 1859835 Intrastat: 84718000 SKU: RNUC11BTMI70002
Pricing and stock details are available to registered users only.
| Type | PC barebone |
| Product Form Factor | Mini PC |
| Localisation | Region: Europe |
| CPU | Intel Core i7 (11th Gen) 11700B |
| Clock Speed | 3.2 GHz |
| Max Turbo Speed | 4.8 GHz |
| Number of Cores | 8-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Processor Main Features | Intel Virtualization Technology, Intel AES New Instructions, Intel Platform Trust Technology (PTT) |
| Chipset Type | Intel WM590 |
| Installed Size | 24 MB |
| Cache Per Processor | 24 MB |
| Installed Size | 0 GB / 64 GB (max) |
| Technology | DDR4 SDRAM |
| Form Factor | SO-DIMM 260-pin |
| Slots | 2 (Total) / 2 (empty) |
| Type | No HDD |
| Type | 1 x SATA/NVMe |
| Controller Interface Type | SATA 6Gb/s / PCIe 4.0 x4 (NVMe) |
| RAID Level | RAID 0, RAID 1 |
| Type | No optical drive |
| Type | Card reader |
| Supported Flash Memory Cards | SDXC UHS-II Memory Card |
| Monitor Type | None. |
| Interface Type | Thunderbolt 4 / HDMI |
| Graphics Processor | Intel UHD Graphics |
| Video Interfaces | HDMI, USB-C |
| Max Monitors Supported | 3 |
| Sound Output Mode | 7.1 channel surround |
| Compliant Standards | High Definition Audio |
| Ethernet Ports | 2.5 Gigabit Ethernet |
| Ethernet Controller | Intel I225-LM |
| Wireless LAN Supported | Yes |
| Wireless NIC | Intel Wi-Fi 6E AX 210 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.2 |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6, Bluetooth 5.2 |
| Slots | 1 (total) / 1 (free) x M.2 Card - 2280 (PCIe 4.0 x4 mode) ¦ 2 (total) / 2 (free) x M.2 Card - 2242/2280 (SATA/PCIe 3.0 x4 (NVMe)) ¦ 1 (total) / 1 (free) x M.2 Card - 2280/22110 (PCIe 4.0 x4 mode) ¦ 1 (total) / 1 (free) x PCIe 4.0 x16 - double-width ¦ 1 (total) / 1 (free) x PCIe 4.0 x4 |
| Interfaces | 2 x Thunderbolt 4/USB-C 3.2 Gen 2 ¦ 1 x HDMI ¦ 6 x USB 3.2 Gen 2 (6 rear) ¦ 1 x LAN (2.5Gigabit Ethernet) ¦ 1 x headphones/microphone - mini-jack ¦ 2 x USB 3.2 Gen 2 (2 in front) |
| Device Type | Power supply |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Provided | 650 Watt |
| 80 PLUS Certification | 80 PLUS Gold |
| Service & Support | Limited warranty - 3 years |
| Width | 12 cm |
| Depth | 35.7 cm |
| Height | 18.9 cm |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 35 °C |
