Datalogic DL-Axist - Dock charger - data collection terminal - rugged - Android 4.4.4 (KitKat) - 8 GB eMMC - 5" TFT (1280 x 720) - rear camera - barcode reader - (2D imager) - USB host - microSD slot - Wi-Fi, Bluetooth, NFC
images are for illustrative purposes only
New
Article: 1903740 Intrastat: 84713000 SKU: 944600006
Pricing and stock details are available to registered users only.
| Product Type | Data collection terminal - rugged |
| Operating System | Android 4.4.4 (KitKat) |
| Type | 5" TFT - LED backlight |
| Resolution | 1280 x 720 |
| Touchscreen | Multi-Touch |
| Features | 5-point multi-touch, Corning Gorilla glass 3, glove touch mode |
| Processor | Texas Instruments OMAP4430 |
| Processor Clock Speed | 1 GHz |
| Number of Cores | Dual-Core |
| Storage | 8 GB eMMC |
| RAM | 1 GB |
| Supported Flash Memory Cards | microSD, microSDHC |
| Wireless Connectivity | 802.11a/b/g/n, Bluetooth 4.0, NFC |
| Sensor Resolution | 5 Megapixel |
| Focus Adjustment | Automatic |
| Light Source | LED light |
| Receiver | A-GPS/GLONASS/BeiDou |
| Type | Touch-screen |
| Barcode Reader | Yes |
| Scan Element Type | 2D imager |
| Barcodes | GS1 DataBar, QR code, MaxiCode, Aztec code, MicroPDF417, Postnet, PDF417, Data Matrix, PLANET, Australian Post, Japanese Post, Kix (Netherlands) Post, RM4SCC, Royal Mail |
| Minimum Bar Width | 3 mil |
| Preloaded Software | Datalogic Android SDK |
| Expansion Slots | 1 x microSDHC |
| Interfaces | 1 x Micro-USB ¦ 1 x dock |
| USB Host | Yes |
| Installed Qty (Max Supported) | 1 |
| Technology | Lithium Ion |
| Capacity | 11.8 Wh |
| Features | Water-resistant, Green Spot technology, LED indicator, drop-resistant, MIMO technology |
| Included Accessories | Protective bumper |
| Compliant Standards | RoHS, ISO 15693, CCX V4, IP67, IEC 60825-1:2007, IEC 62471, EN 60825-1:2007, 21 CFR 1040 |
| Width | 8 cm |
| Depth | 1.9 cm |
| Height | 15.7 cm |
| Weight | 350 g |
| Service & Support | Limited warranty - 1 year |
| Min Operating Temperature | -20 °C |
| Max Operating Temperature | 50 °C |
| Min Storage Temperature | -30 °C |
| Max Storage Temperature | 70 °C |
