Zebra TC77 - Data collection terminal - rugged - Android 8.1 (Oreo) - 32 GB - 4.7" (1280 x 720) - rear camera + front camera - barcode reader - (2D imager) - USB host - microSD slot - Wi-Fi 5, NFC, Bluetooth - 4G - LTE

  • TC77 WWAN SE4750 F/R CAM 4/32 A8.1-G WW
  • TC77 WWAN SE4750 F/R CAM 4/32 A8.1-G WW
  • TC77 WWAN SE4750 F/R CAM 4/32 A8.1-G WW
  • TC77 WWAN SE4750 F/R CAM 4/32 A8.1-G WW
  • TC77 WWAN SE4750 F/R CAM 4/32 A8.1-G WW
  • TC77 WWAN SE4750 F/R CAM 4/32 A8.1-G WW
images are for illustrative purposes only

New

Article: 1548009 Intrastat: 84713000 SKU: TC77HL-5ME24BG-A6 Barcode: TC77HL-5ME24B
Pricing and stock details are available to registered users only.
 Add to compare
Product TypeData collection terminal - rugged
Operating SystemAndroid 8.1 (Oreo)
Type4.7" - LED backlight
Resolution1280 x 720
TouchscreenMulti-Touch
FeaturesCorning Gorilla glass, Capacitive Dual Touch Display Technology, outdoor viewable, glove touch mode, optical bonding
ProcessorQualcomm Snapdragon 660
Processor Clock Speed2.2 GHz
Number of Cores8-core
Storage32 GB
RAM4 GB
Supported Flash Memory CardsmicroSD, microSDHC, microSDXC
Max Supported Capacity256 GB
Cellular Technology4G
Cellular ProtocolsGSM, GPRS, UMTS, EDGE, HSPA, HSPA+, LTE
BandGSM 850/900/1800/1900 / UMTS 850/900/1900/2100 / LTE 700/800/850/900/1800/1900/2100/2600
Wireless Connectivity802.11a/b/g/n/ac, NFC, Bluetooth 5.0
Security Protocols & FeaturesLEAP, WEP, WPA, WPA2, TKIP, AES, EAP-TTLS, EAP-TLS, WPA2-Enterprise, PAP, MS-CHAP, MS-CHAPv2, PEAPv0, PEAPv1
Sensor Resolution13 Megapixel
Lens ApertureF/2.2
Light SourceLED flash
FeaturesQR-code scanner
Sensor Resolution0.3 Megapixel
FunctionsIR camera
Sensor Resolution5 Megapixel
Lens ApertureF/2.0
ReceiverA-GPS/GPS/GLONASS/Gallileo/Beidou
AudioThree microphones, speaker
TypeTouch-screen
Barcode ReaderYes
Scan Element Type2D imager
BarcodesCode 39
Max Working Distance92.2 cm
Minimum Bar Width3 mil
Preloaded SoftwareGoogle Mobile Services
Expansion Slots2 x Nano-SIM card ¦ 1 x microSD
Interfaces1 x USB 2.0
USB HostYes
TechnologyPowerPrecision+ - Lithium Ion
Capacity4620 mAh
SensorsAmbient light sensor, 3-axis gyro sensor, digital compass, 3-axis accelerometer
FeaturesInteractive Sensor Technology (IST), MIMO technology, SE4750 Standard Range Array Imager, 256 QAM Modulation on 5G GHz radio, Low-Density Parity Check (LDPC)
Vibrating AlertYes
Compliant StandardsISO 14443 type A, MIL-STD 810G, ISO 14443 type B, ISO 15693, IP67, IP65, FeliCa
Width8.4 cm
Depth2.8 cm
Height16.1 cm
Weight376 g
Service & SupportLimited warranty - 1 year
Min Operating Temperature-20 °C
Max Operating Temperature50 °C
Humidity Range Operating5 - 95% (non-condensing)
Min Storage Temperature-40 °C
Max Storage Temperature70 °C
