Eaton Ellipse ECO 650 USB DIN - UPS (rack-mountable / external) - AC 230 V - 400 Watt - 650 VA - USB - output connectors: 4 - 2U - 19"
images are for illustrative purposes only
New
Article: 418964 Intrastat: 84734080 SKU: EL650USBDIN
Pricing and stock details are available to registered users only.
| Device Type | UPS - rack-mountable / external |
| Height (Rack Units) | 2U |
| Rack Size | 19" |
| UPS Technology | Off-line |
| Input Voltage | AC 230 V |
| Input Voltage Range | AC 184 - 264 V |
| Input Voltage Range (Adjustable) | AC 161 - 284 V |
| Frequency Provided | 50/60 Hz |
| Frequency Required | 50/60 Hz |
| Input Connectors | 1 x power |
| Power Output Connectors Details | 3 (UPS and surge) ¦ 1 (surge) |
| Output Voltage | AC 220/230/240 V 50/60 Hz |
| Power Capacity | 400 Watt / 650 VA |
| Dataline Surge Protection | Network/phone line - RJ-45/RJ-11 |
| Surge Suppression | Yes |
| Circuit Protection | Circuit breaker |
| Technology | Lead Acid |
| Run Time (Up To) | 9 min at half load ¦ 6 min at 70% load |
| Remote Management Interface | USB |
| Interfaces | 1 x management (USB) - 4 pin USB Type B |
| Cables Included | USB cable - external |
| Rack Mounting Kit | Optional |
| Features | Wall mountable, audible alarm, LED indicators, deep discharge protection, cold-start function, Eco-efficiency |
| Compliant Standards | CB, IEC 62040-1-1, IEC 62040-2, IEC 60950-1, IEC 61643-1 |
| Software Included | Intelligent Power Manager |
| OS Required | Linux, Apple MacOS X, Microsoft Windows Vista / XP / 7 |
| Service & Support | Limited warranty - 2 years |
| Width | 8.1 cm |
| Depth | 23.5 cm |
| Height | 26.3 cm |
| Weight | 3.6 kg |
