Elo 3243L Projected Capacitive - LED monitor - 32" (31.5" viewable) - open frame - touchscreen - 1920 x 1080 Full HD (1080p) @ 60 Hz - 500 cd / m² - 3000:1 - 8 ms - HDMI, VGA - black

  • Elo Touchsystems 3243L 32IN LCD OPEN FRAME FHD (PCAP 10-TP USB VGA/HDMI IN)
  • Elo Touchsystems 3243L 32IN LCD OPEN FRAME FHD (PCAP 10-TP USB VGA/HDMI IN)
  • Elo Touchsystems 3243L 32IN LCD OPEN FRAME FHD (PCAP 10-TP USB VGA/HDMI IN)
  • Elo Touchsystems 3243L 32IN LCD OPEN FRAME FHD (PCAP 10-TP USB VGA/HDMI IN)
  • Elo Touchsystems 3243L 32IN LCD OPEN FRAME FHD (PCAP 10-TP USB VGA/HDMI IN)
  • Elo Touchsystems 3243L 32IN LCD OPEN FRAME FHD (PCAP 10-TP USB VGA/HDMI IN)
images are for illustrative purposes only

New

Article: 1302341 Intrastat: 85285291 SKU: E304029 Barcode: 834619008641
Pricing and stock details are available to registered users only.
 Add to compare
  • Easily integrated
  • Touch ready
  • Commercial-grade
The Elo 3243L 32-inch Full HD open-frame touchscreen delivers a professional-grade large-format display and sleek design. Designed for touch from the start with proven Elo expertise and reliability built-in, the 3243L offers a state-of-the-art slim design, using LED backlighting, reducing power consumption and heat to enable thinner and smaller kiosk designs for various applications in retail, hotels, gaming, transportation and other commercial uses. The touchscreen glass supports applications in demanding public-access environments. The comprehensive range of features combines analog and digital interfaces, multi-lingual and cabled remote on-screen display (OSD), mounting VESA standard, mounting brackets, and worldwide compliance.



Display TypeLED-backlit LCD monitor / TFT active matrix
Diagonal Size32"
Viewable Size31.5"
Aspect Ratio16:9
Native ResolutionFull HD (1080p) 1920 x 1080 at 60 Hz
Brightness500 cd/m²
Brightness w/touchscreen425 cd/m²
Contrast Ratio3000:1
Colour Support16.7 million colours
Response Time8 ms
Vertical Refresh Rate47 - 63 Hz
Horizontal Refresh Rate31.5 - 80 kHz
Horizontal Viewing Angle+89 / -89
Vertical Viewing Angle+89 / -89
Backlight TechnologyLED backlight
Controls & AdjustmentsMute, volume, brightness, contrast, H/V position, sharpness, input select, colour temperature, phase, clock, aspect control
OSD LanguagesChinese (traditional), Chinese (simplified), English, German, French, Italian, Spanish, Japanese
FeaturesHDCP, OSD lock, Full HD wide-viewing angle (WVA), Projected Capacitive Touch (P-CAP) technology
ColourBlack
Dimensions (WxDxH)73.64 cm x 5.8 cm x 44.3 cm
Weight11.2 kg
TypeTouch-screen - touchscreen
Movement Detection TechnologyProjected capacitive
InterfacesVGA ¦ HDMI ¦ USB (Type B)
VESA Mounting Interface400 x 200 mm
Mounting KitIncluded
MTBF50,000 hour(s)
Compliant StandardsUL, VCCI, C-Tick, BSMI, cUL, UL 60950, CB, CCC, IC, FCC, RoHS, KCC, WEEE, S Mark, E-Standby, KC, EAC, China RoHS, CoC
LocalisationWorldwide
Input VoltageAC 120/230 V (50/60 Hz)
Power Consumption (Typical)49.6 Watt
Power Consumption Stand by0.9 Watt
Power Consumption Sleep0.1 Watt
Service & SupportLimited warranty - 3 years
Min Operating Temperature0 °C
Max Operating Temperature40 °C
Humidity Range Operating20 - 80% (non-condensing)
