Supermicro MicroBlade MBM-XEM-002 - Switch - Managed - 2 x 40 Gigabit QSFP + 4 x 10 Gigabit SFP+ (uplink) - plug-in module
images are for illustrative purposes only
New
Article: 1836971 Intrastat: 85176990 SKU: 10-002-2
Pricing and stock details are available to registered users only.
| Device Type | Switch - Managed |
| Enclosure Type | Plug-in module |
| Subtype | 40 Gigabit Ethernet |
| Ports | 2 x 40 Gigabit QSFP + 4 x 10 Gigabit SFP+ (uplink) |
| Performance | Switching capacity: 1280 Gbps |
| Capacity | VLANs supported: 4000 |
| Jumbo Frame Support | 9KB |
| Remote Management Protocol | SNMP 1, SNMP 2, RMON, SNMP 3, SSH, CLI |
| Encryption Algorithm | SSL |
| Authentication Method | Secure Shell (SSH), RADIUS, TACACS+ |
| Features | Flow control, DHCP support, IGMP snooping, Syslog support, port mirroring, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Jumbo Frames support, LLDP support, Storm Control, IP source guard, Network Timing Protocol (NTP) |
| Compliant Standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s, IEEE 802.1ab (LLDP) |
| Processor | 1 BCM56846 |
| Interfaces | 1 x console 2 x 40Gbit LAN QSFP 4 x 10Gbit LAN SFP+ uplink 1 x USB |
| Software Included | Command Line Interface (CLI) |
| Width | 26.7 cm |
| Depth | 15.9 cm |
| Height | 3.6 cm |
| Weight | 1.5 kg |
