Ubiquiti NanoStation ac NS-5AC - Radio access point - AirMax ac - AirMax ac

  • UBIQUITI NS-5AC-EU
  • UBIQUITI NS-5AC-EU
  • UBIQUITI NS-5AC-EU
images are for illustrative purposes only

New

Article: 1677611 Intrastat: 85176930 SKU: NS-5AC-EU
Pricing and stock details are available to registered users only.
 Add to compare
Device TypeRadio access point
Ruggedized DesignOutdoor, indoor
Width8.4 cm
Depth3 cm
Height25.7 cm
Weight233 g
LocalisationEurope
Processors Installed1 x Atheros MIPS 74KC 560 MHz
Max Supported Qty1
RAM64 MB DDR2 SDRAM
Form FactorExternal
Connectivity TechnologyWireless
Data Transfer Rate450 Mbps
Line Coding Format64 QAM, 256 QAM
Data Link ProtocolAirMax ac
Frequency Band5 GHz
Max Range Open Space15 km
Status IndicatorsPower, signal strength, LAN
FeaturesPower over Ethernet (PoE), MIMO technology, Auto Channel Select (ACS), pole mountable, Time Division Multiple Access (TDMA), Distance Control (ACK Timeout), spectrum analyser, dual-linear polarisation, Point-to-Point (PtP) link mode
Encryption AlgorithmWPA2
Compliant StandardsIEEE 802.3af
AntennaInternal
Gain Level16 dBi
Interfaces2 x 1000Base-T (PoE) - RJ-45
Included AccessoriesPole mount
Compliant StandardsIC, FCC, RoHS, ETSI 300 019-1-4
Power Consumption Operational8.5 Watt
OS ProvidedAirOS 8
Min Operating Temperature-40 °C
Max Operating Temperature70 °C
Humidity Range Operating5 - 95% (non-condensing)
