TP-Link Archer A5 - Wireless router - 4-port switch - 802.11a / b / g / n / ac - Dual Band
TP-Link Archer A5 - Wireless router - 4-port switch - 802.11a / b / g / n / ac - Dual Band
Manufacturer
•TP-LINK
Reference
•ARCHER A5
Article
•3160961
Intrastat
•85176930
Total quantity in stocks
•20
Nearest delivery
•25.06.2026
Ethernet WAN
Y
DSL WAN
N
SIM card slot
N
3G/4G USB modem compatibility
N
WAN connection type
RJ-45
Wi-Fi band
Dual-band (2.4 GHz / 5 GHz)
Top Wi-Fi standard
Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)
867 Mbit/s
Wi-Fi standards
802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
WLAN data transfer rate (first band)
300 Mbit/s
WLAN data transfer rate (second band)
867 Mbit/s
Ethernet LAN
Y
Ethernet LAN interface type
Fast Ethernet
Ethernet LAN data rates
10,100 Mbit/s
Cabling technology
10/100Base-T(X)
Networking standards
IEEE 802.3, IEEE 802.3u
Port forwarding
Y
Dynamic DNS (DDNS)
Y
Static route
Y
VPN Passthrough
Y
Receiver sensitivity
5GHz:
11a 54M: -73dBm
11ac VHT20 MCS8: -68dBm
11ac VHT40 MCS9: -64dBm
11ac VHT80 MCS9: -60dBm
2.4GHz:
11g 54M: -76dBm
11n HT20 MCS7: -74dBm
11n HT40 MCS7: -71dBm
Mobile network generation
4G
3G
N
4G
N
Ethernet LAN (RJ-45) ports
4
USB port
N
Memory card slot(s)
N
Reset button
Y
WPS push button
Y
Security algorithms
64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Firewall
Y
Access Control List (ACL)
Y
DoS attack prevention
Y
Filtering
Y
MAC address filtering
Y
IP address filtering
Y
DMZ support
Y
DHCP client
Y
DHCP server
Y
Universal Plug and Play (UPnP)
Y
Supported network protocols
IPv4, IPv6
Product type
Tabletop router
Product colour
White
Cables included
LAN (RJ-45)
AC adapter included
Y
Quick installation guide
Y
Antenna design
External
Antennas quantity
4
Certification
CE, FCC, RoHS
Power source type
DC
Output voltage
9 V
Output current
0.85 A
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
5 - 90%
Windows operating systems supported
Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows Vista, Windows XP
Linux operating systems supported
Y
Mac operating systems supported
macOS
Mac compatibility
Y
Width
229.9 mm
Depth
144.2 mm
Height
36.9 mm
Package width
290 mm
Package depth
240 mm
Package height
76 mm
