AXIS Q1798-LE - Network surveillance camera - weatherproof - colour (Day&Night) - 10 MP - 3840 x 2160 - 3840 / 30p - audio - GbE - MJPEG, H.264 - PoE Class 3
images are for illustrative purposes only
New
Article: 1719271 Intrastat: 84716070 SKU: 01702-001
Pricing and stock details are available to registered users only.
| Device Type | Network surveillance camera |
| Audio Support | Yes |
| Audio Formats | G.726, ADPCM, AAC-LC, LPCM, G.711, OPUS |
| Connectivity Technology | Wired |
| Width | 36 cm |
| Depth | 14.7 cm |
| Height | 14.7 cm |
| Weight | 2.55 kg |
| Type | Colour - Day&Night - fixed - weatherproof |
| Digital Video Format | MJPEG, H.264 |
| Max Digital Video Resolution | 3840 x 2160 |
| Motion Detection | Yes |
| Video Modes | 3840/30p |
| Exposure Range | 2 sec - 1/45500 sec |
| Minimum Illumination | 0.03 lux - colour - F1.7 - 50 IRE ¦ 0.006 lux - B&W - F1.7 - 50 IRE ¦ 0 lux - IR - F1.7 |
| Infrared LEDs | Yes |
| Infrared Distance | 100 m |
| Digital Video Capture Resolution | 3840 x 2160, 160 x 90, 3712 x 2784 |
| Frame Rate (max) | 30 frames per second |
| RAM | 2 GB |
| Flash Memory | 512 MB |
| Features | Sharpness control, white balance, saturation control, brightness control, contrast control, image mirror, defogger, Privacy Mask Function, NAS-Ready, active tampering alarm, password protection, distortion correction function, shock detection, auto-rotation mode, Auto Focus, ONVIF (Profile S) support, ONVIF (Profile G) support, image overlay, Pixel Counter Support, infrared-cut filter, digest authentication, Forensic WDR, IP address filtering, electronic image stabilisation, exposure zone, HTTPs encryption, Lightfinder 2.0 technology |
| Type | 10 MP RGB BSI CMOS 4/3" |
| Optical Zoom | 4 x |
| Focal Length | 12 mm - 48 mm |
| Lens Iris | F/1.7-4.0 |
| Focus Adjustment | Automatic |
| Horizontal Field of View (degree) | 20 - 90 |
| Vertical Field of View (degree) | 12 - 62 |
| Network Interface | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Network Protocols | DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, SMB, IGMP, SSH, SSL, QOS, CIFS, SRTP, SFTP, LLDP, USGv6 |
| Ports | LAN - RJ-45 ¦ LAN/power - terminal block ¦ Audio line-in/microphone - 3.5 mm jack |
| Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
| Included Accessories | Connector kit, Resistorx L-key |
| Cables Included | 1 x network cable |
| Compliant Standards | EN55024, EN 61000-6-1, EMC, ICES-003 Class A, EN 61000-6-2, IEC 60068-2-30, IEC 60068-2-27, IEC 60068-2-6, IP67, IK10, FCC Part 15 B Class A, IP66, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 62262 IK08, EN 50121-4, IEC 62236-4, VCCI Class A, EN 50581, EAC, KN35, NEMA250 Type 4X, AS/NZS CISPR 32 Class A, EN 55032 Class A, KCC KN32 Class A, IEC/EN/UL 60950-22, IEC/EN 62471, IEEE 802.3af, IEEE 802.3at, IEC/EN/UL 62368-1, IEEE 802.1x |
| Colour | White |
| Power Requirements | PoE Class 3 |
| Software Included | Windows decoder 1-user licence, AXIS Fence Guard, AXIS Video Motion Detection, AXIS Loitering Guard, AXIS Motion Guard |
| Service & Support | Limited warranty - 3 years |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 60 °C |
| Relative Humidity (operating) | 10 - 100% |
