Synology Disk Station DS223J - NAS server - SATA 6Gb / s - RAID RAID 0, 1, JBOD - RAM 1 GB - Gigabit Ethernet - iSCSI support
images are for illustrative purposes only
New
Article: 3183151 Intrastat: 84717020 SKU: DS223J
Pricing and stock details are available to registered users only.
| Device Type | NAS server |
| Host Connectivity | Gigabit Ethernet |
| Max Supported Capacity | 108 TB |
| Width | 10 cm |
| Depth | 22.55 cm |
| Height | 16.5 cm |
| Weight | 880 g () |
| Processors Installed | 1 x Realtek Semiconductor RTD1619B 1.7 GHz |
| Number of Cores | Quad-Core |
| Max Supported Qty | 1 |
| RAM | 1 GB DDR4 |
| Type | RAID |
| Interface Type | SATA 6Gb/s |
| RAID Level | RAID 0, RAID 1, JBOD |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, GigE |
| Network / Transport Protocol | iSCSI, FTP, SMB, NFS, HTTP, HTTPs, SMB v2, SMB v3, CIFS |
| Remote Management Protocol | SNMP, HTTP, HTTPS, LDAP |
| Network Services Compatibility | Network File System (NFS), FTP, Server Message Block (SMB), Apple File Protocol (AFP), HTTP, HTTPS, Web-based Distributed Authoring and Versioning (WebDAV), Calendaring Extensions to WebDAV (CalDAV), Server Message Block 2.0 (SMB 2.0), Server Message Block 3.0 (SMB 3.0), Network File System v3 (NFS v3), Network File System v4 (NFS v4), Network File System v4.1 (NFS v4.1) |
| Performance | Maximum volume size: 108 TB ¦ Maximum number of volume: 64 ¦ Maximum concurrent connections: 200 ¦ Local user account: 1024 ¦ Local group account: 256 ¦ Maximum number of shared folder: 256 ¦ Maximum number of shared folders syncing tasks: 4 ¦ Hybrid share folder number: 5 ¦ Syslog: 400 events per second |
| Features | Hardware encryption, wake on LAN (WOL), Access Control List (ACL) support, VPN Server, B-tree file system (Btrfs), USB One Touch Copy, EXT4 file system, SSD trim, wake on WAN (WOW), NFS Kerberos authentication, cloud sync |
| Compliant Standards | DLNA CERTIFIED |
| IP Cameras Supported | 12 |
| Compression Format | H.264, H.265 |
| Image Resolution | 1280x720, 1920x1080, 2048x1536, 2591x1944, 3840x2160 |
| Expansion Bays | 2 (total) / 2 (free) x hot-swap - 2.5" / 3.5" |
| Interfaces | 3 x USB 3.2 Gen 1 - Type A ¦ 1 x Ethernet 1000Base-T - RJ-45 |
| Cables Included | 1 x network cable |
| Features | 92mm cooling fan |
| Compliant Standards | VCCI, BSMI, CCC, FCC, RoHS, KC, EAC, RCM, UKCA |
| Included Accessories | Accessory pack, power cable |
| Power Device | External power adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 16.31 Watt |
| Power Consumption Stand by | 4 Watt |
| Power Provided | 60 Watt |
| Service & Support | Limited warranty - 2 years |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 5 - 95% RH |
| Sound Emission | 18.2 dBA |
