HPE Smart Array P431 / 4GB with FBWC - Storage controller (RAID) - 8 Channel - SATA 6Gb / s / SAS 12Gb / s - low profile - RAID 0, 1, 5, 6, 10, 50, 60, 1 ADM, 10 ADM - PCIe 3.0 x8 - for ProLiant ML350e Gen8 v2, ML350e Gen8 v2 Base
images are for illustrative purposes only
New
Article: 4160284 SKU: 698532-B21
Pricing and stock details are available to registered users only.
| Device Type | Storage controller (RAID) - plug-in card - low profile |
| Host Bus | PCIe 3.0 x8 |
| Interface | SATA 6Gb/s / SAS 12Gb/s |
| Data Transfer Rate | 12 Gbit/s |
| Buffer Size | 4 GB |
| Supported Devices | Disk array (RAID) |
| Channel Qty | 8 |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM |
| Interfaces | 2 x SATA 6Gb/s / SAS 12Gb/s (internal) |
| Compliant Standards | WEEE, REACH |
| OS Required | SuSE Linux Enterprise Server 11, Microsoft Windows Server 2008 R2, Red Hat Enterprise Linux 5, Red Hat Enterprise Linux 6, Microsoft Windows Server 2012, VMware ESXi 5.0 update 2, VMware ESXi 5.1 update 1, VMware vSphere 5.5 |
| Width | 5.72 cm |
| Depth | 24.13 cm |
| Height | 19.05 cm |
| Weight | 450 g |
| Designed For | HPE ProLiant ML350e Gen8 v2, ML350e Gen8 v2 Base |
