Fujitsu PRIMERGY RX2520 M5 - Server - rack-mountable - 2U - 2-way - 1 x Xeon Silver 4208 / 2.1 GHz - RAM 16 GB - SATA - hot-swap 2.5" bay(s) - no HDD - GigE - no OS - monitor: none
images are for illustrative purposes only
New
Article: 2828897 SKU: VFY:R2525SC010IN
Pricing and stock details are available to registered users only.
| Processor family | Intel Xeon Silver |
| Processor manufacturer | Intel |
| Processor model | 4208 |
| Processor frequency | 2.1 GHz |
| Processor generation | 2nd Generation Intel® Xeon® Scalable |
| Processor boost frequency | 3.2 GHz |
| Processor cores | 8 |
| Processor cache | 11 MB |
| Motherboard chipset | Intel® C624 |
| Number of processors installed | 1 |
| Thermal Design Power (TDP) | 85 W |
| Maximum number of SMP processors | 2 |
| Processor socket | LGA 3647 (Socket P) |
| Processor lithography | 14 nm |
| Processor threads | 16 |
| Processor operating modes | 64-bit |
| Processor codename | Cascade Lake |
| Tcase | 78 °C |
| Maximum internal memory supported by processor | 1024 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2400 MHz |
| Execute Disable Bit | Y |
| Maximum number of PCI Express lanes | 48 |
| Processor package size | 76.0 x 56.5 mm |
| Supported instruction sets | AVX-512 |
| Scalability | 2S |
| Embedded options available | N |
| Internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| Maximum internal memory | 384 GB |
| Memory slots | 12 |
| Memory clock speed | 2933 MHz |
| RAID support | Y |
| Optical drive type | DVD-RW |
| Number of HDDs supported | 8 |
| RAID levels | 0, 1, 10 |
| Hot-Plug support | Y |
| Hot-swap | Y |
| On-board graphics card model | Not available |
| Ethernet LAN | Y |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN (RJ-45) ports | 2 |
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 6 |
| VGA (D-Sub) ports quantity | 1 |
| PCI Express x8 (Gen 3.x) slots | 3 |
| PCI Express x16 (Gen 3.x) slots | 1 |
| PCI Express slots version | 3.0 |
| Chassis type | Rack (2U) |
| Rack mounting | Y |
| Redundant fans support | Y |
| Rack rails | Y |
| Operating system installed | N |
| Compatible operating systems | Microsoft Hyper-V Server 2016 Microsoft Windows Server 2016 Datacenter Microsoft Windows Server 2016 Standard Microsoft Windows Server 2016 Essentials Microsoft Windows Storage Server 2016 Standard Microsoft Hyper-V Server 2012 R2 Microsoft Windows Server 2012 R2 Datacenter Microsoft Windows Server 2012 R2 Standard Microsoft Windows Server 2012 R2 Essentials Microsoft Windows Storage Server 2012 R2 Standard VMware vSphere 6.5 VMware vSphere 6.0 SUSE Linux Enterprise Server 12 Red Hat Enterprise Linux 7 Red Hat Enterprise Linux 6 Univention Corporate Server 4 |
| Enhanced Intel SpeedStep Technology | Y |
| Intel Virtualization Technology for Directed I/O (VT-d) | Y |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Y |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® AES New Instructions (Intel® AES-NI) | Y |
| Intel Trusted Execution Technology | Y |
| Intel VT-x with Extended Page Tables (EPT) | Y |
| Intel TSX-NI | Y |
| Intel 64 | Y |
| Intel Virtualization Technology (VT-x) | Y |
| Processor ARK ID | 193390 |
| Redundant power supply (RPS) support | Y |
| Power supply | 450 W |
| Operating temperature (T-T) | 5 - 45 °C |
| Operating relative humidity (H-H) | 10 - 85% |
| Certification | CB, RoHS, WEEE, GS, CE, CSAc/us, FCC Class A, ICES-003/NMB-003 Class A, VCCI:V3 Class A + JIS 61000-3-2, EAC, KC, CCC, RCM, BSMI |
| Width | 482.4 mm |
| Depth | 770 mm |
| Height | 86.6 mm |
| Weight | 25 kg |
