Supermicro SuperServer 6019P-WTR - Server - rack-mountable - 1U - 2-way - no CPU - RAM 0 GB - SATA - hot-swap 3.5" bay(s) - no HDD - AST2500 - GigE - no OS - monitor: none - black
images are for illustrative purposes only
New
Article: 1614562 SKU: SYS-6019P-WTR
Pricing and stock details are available to registered users only.
| Type | Server |
| Product Form Factor | Rack-mountable - 1U |
| Server Scalability | 2-way |
| Front Accessible Bays Qty | 1 |
| Hot-Swap Bays Qty | 4 |
| Colour | Black |
| CPU | No CPU |
| Max CPU Qty | 2 |
| CPU Upgradability | Upgradable |
| CPU Socket | Socket P |
| Chipset Type | Intel C621 |
| Installed Size | 0 GB / 1.5 TB (max) |
| Technology | DDR4 SDRAM - ECC |
| Form Factor | DIMM 288-pin |
| Slots | 12 (Total) / 12 (empty) |
| Features | Registered, 3DS Load-Reduced DIMM (LRDIMM) |
| RAM Supported | 1.5 TB 3DS Load-Reduced - ECC ¦ 768 GB registered - ECC |
| Type | No HDD |
| Type | 1 x SATA |
| Controller Interface Type | SATA 6Gb/s |
| Channel Qty | 4 |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 10 |
| Type | No optical drive |
| Monitor Type | None. |
| Graphics Processor | ASPEED AST2500 |
| Video Interfaces | VGA |
| Ethernet Ports | 2 x Gigabit Ethernet |
| Ethernet Controller | Intel X722 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol | IPMI 2.0 |
| Features | ACPI support, KVM over IP support |
| Bays | 4 (total) / 4 (free) x hot-swap 3.5" |
| Slots | 2 CPU ¦ 12 (total) / 12 (free) x DIMM 288-pin ¦ 2 (total) / 2 (free) x PCIe 3.0 x16 - full-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - low-profile ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 ¦ 1 (total) / 1 (free) x M.2 Card |
| Interfaces | 2 x LAN (Gigabit Ethernet) ¦ 1 x management - RJ-45 ¦ 4 x USB 3.0 ¦ 1 x VGA |
| Included Accessories | 2 x CPU Heatsink, 2 x riser cards, 2 x air shrouds |
| Cables Included | Serial ATA / SAS cable |
| Compliant Standards | RoHS |
| Device Type | Power supply |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1+1 |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Voltage Required | AC 120/230 V (50 - 60 Hz) |
| Power Provided | 750 Watt |
| 80 PLUS Certification | 80 PLUS Platinum |
| OS Provided | No operating system |
| Service & Support | Limited warranty - parts - 1 year ¦ Limited warranty - labour - 3 years |
| Width | 43.7 cm |
| Depth | 59.7 cm |
| Height | 4.3 cm |
| Weight | 20.9 kg |
| Min Operating Temperature | 10 °C |
| Max Operating Temperature | 35 °C |
| Humidity Range Operating | 8 - 90% (non-condensing) |
