HPE ProLiant ML350 Gen10 Base - Server - tower - 4U - 2-way - 1 x Xeon Silver 4208 / 2.1 GHz - RAM 16 GB - SATA / SAS - hot-swap 2.5" bay(s) - no HDD - GigE - no OS - monitor: none - BTO
images are for illustrative purposes only
New
Article: 3169166 SKU: P59547-421
Pricing and stock details are available to registered users only.
| Type | Server |
| Product Form Factor | Tower - 4U |
| Server Scalability | 2-way |
| Hot-Swap Bays Qty | 8 |
| Localisation | Region: EMEA |
| CPU | Intel Xeon Silver 4208 |
| Clock Speed | 2.1 GHz |
| Max Turbo Speed | 3.2 GHz |
| Number of Cores | 8-core |
| CPU Qty | 1 |
| Max CPU Qty | 2 |
| CPU Upgradability | Upgradable |
| Processor Main Features | Hyper-Threading Technology, Intel Turbo Boost Technology 2 |
| CPU Socket | FCLGA3647 Socket |
| Chipset Type | Intel C622 |
| Installed Size | L3 Cache - 11 MB |
| Cache Per Processor | 11 MB |
| Installed Size | 16 GB / 1.5 TB (max) |
| Technology | DDR4 SDRAM - Advanced ECC |
| Effective Memory Speed | 2400 MHz |
| Rated Memory Speed | 2933 MHz |
| Form Factor | DIMM 288-pin |
| Slots | 12 (Total) / 11 (empty) |
| Features | Registered, single rank, slots 13 - 24 are available in two-processor configuration only, HPE SmartMemory |
| Configuration Features | 1 x 16 GB |
| RAM Supported | 3 TB Load-Reduced ¦ 1.5 TB registered |
| Type | No HDD |
| Type | 1 x RAID - PCIe 3.0 x8 |
| Controller Interface Type | SATA 6Gb/s / SAS 12Gb/s |
| Storage Controller Name | HPE Smart Array P408i-a SR Gen10 |
| Channel Qty | 8 |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM |
| Buffer Size | 2 GB |
| Type | No optical drive |
| Monitor Type | None. |
| Video Memory | 16 MB |
| Video Interfaces | VGA, DisplayPort |
| Ethernet Ports | 4 x Gigabit Ethernet |
| Ethernet Controller | HPE 369i |
| Data Link Protocol | Gigabit Ethernet |
| Remote Management Protocol | SNMP 3, IPMI 2.0 |
| Remote Management Controller | Integrated Lights-Out 5 |
| Features | Wake on LAN (WoL), PXE support |
| Bays | 8 (total) / 8 (free) x hot-swap 2.5" SFF |
| Slots | 2 (total) / 1 (free) x PCIe 3.0 x8 - full-length, full-height (x4 mode) ¦ 2 (total) / 2 (free) x PCIe 3.0 x16 - full-length, full-height ¦ 1 (total) / 1 (free) x microSD Card (internal) |
| Interfaces | 1 x VGA ¦ 1 x serial ¦ 4 x LAN (Gigabit Ethernet) ¦ 1 x HPE iLO - RJ-45 (1 rear) ¦ 5 x USB 3.0 (2 front, 2 rear, 1 internal) ¦ 1 x USB 2.0 (1 internal) ¦ 1 x HPE iLO - Type A (1 in front) (service port) ¦ 1 x DisplayPort |
| Included Accessories | 6 x standard fans |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately), padlock eye |
| Security Slot Type | Kensington security slot |
| Compliant Standards | ASHRAE Class A4, ASHRAE Class A3, ACPI 6.1, Energy-Related Products (ErP) Lot 9 |
| Pricing Type | BTO |
| Device Type | Power supply - hot-plug |
| Power Redundancy | Optional |
| Power Redundancy Scheme | 1+1 (with optional power supply) |
| Installed Qty | 1 |
| Max Supported Qty | 2 |
| Voltage Required | (50/60 Hz) |
| Power Provided | 800 Watt |
| 80 PLUS Certification | 80 PLUS Titanium |
| OS Provided | No operating system |
| Software | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download) |
| ENERGY STAR Certified | Yes |
| ENERGY STAR Version | 2.1 |
| Service & Support | Limited warranty - parts and labour - 3 years - on-site - response time: next business day |
| Width | 17.4 cm |
| Depth | 64.8 cm |
| Height | 46.25 cm |
| Weight | 29 kg |
| Min Operating Temperature | 10 °C |
| Max Operating Temperature | 35 °C |
| Humidity Range Operating | 8 - 90% (non-condensing) |
| Sound Emission | 30 dBA |
