Fractal Design Define Series R6 USB-C Black - TG - Tower - extended ATX - no power supply (ATX) - black - USB/Audio
images are for illustrative purposes only
New
Article: 1856964 Intrastat: 94059900 SKU: TG-C-005-R
Pricing and stock details are available to registered users only.
| Form Factor | Tower |
| Max Mainboard Size | Extended ATX |
| Supported Motherboards | ATX, microATX, Extended ATX, ITX |
| Specification Compliance | ATX |
| Internal Bays Qty | 8 |
| Built-in Devices | 3 x Fractal Design Dynamic X2 GP-14 |
| Product Material | Anodised aluminium, tempered glass, sound-dampened steel |
| Colour | Black |
| Cooling System | Front: 140 mm fan x 2 / intake / 3 x 120 mm or 2 x 140 mm fan supported Top: 120 mm fan mount x 3 / 2 x 140 mm fan supported, open layout 3 x 120/140 mm fan supported Rear: 140 mm fan x 1 / exhaust / 1 x 120/140 mm fan supported Bottom: 120/140 mm fan mount x 2 |
| CPU Cooler Max Height | 185 mm |
| Video Card Max Length | 440 mm |
| System Cabinet Features | Windowed side panel, top panel dust filter, front dust filter, ModuVent, cable management system, supports 120 mm radiator in rear, screwless side panels, supports 120/140/240/280/360 mm radiator in front panel, supports 120/240/360 mm radiator in top, supports 120/140/240/280 mm radiator in bottom, vertical/horizontal graphic card orientation, bottom + PSU dust filter |
| Expansion Bays | 6 (total) / 6 (free) x internal - 2.5" / 3.5" shared 2 (total) / 2 (free) x internal - 2.5" |
| Expansion Slots | 9 |
| Interfaces | 2 x USB 2.0 2 x USB 3.0 1 x USB 3.1 Gen 2 - USB-C 1 x headphones 1 x microphone |
| Included Accessories | Accessory box |
| Power Device | No power supply |
| Width | 23.3 cm |
| Depth | 54.3 cm |
| Height | 46.5 cm |
| Weight | 12.4 kg |
| Shipping Width | 33 cm |
| Shipping Depth | 53.5 cm |
| Shipping Height | 65.5 cm |
| Shipping Weight | 14.2 kg |
