Intel Wi-Fi 7 BE201 - 1st Generation - network adapter - M.2 2230 (CNVio3) - Wi-Fi 6E, Bluetooth, Wi-Fi 7
images are for illustrative purposes only
New
Article: 3354911 Intrastat: 85176990 SKU: BE201.NGWG.NV
Pricing and stock details are available to registered users only.
| Device Type | Network adapter |
| Form Factor | Plug-in card |
| Interface (Bus) Type | M.2 2230 (CNVio3) |
| Connectivity Technology | Wireless |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.4, IEEE 802.11be (Wi-Fi 7) |
| Data Transfer Rate | 5 Gbps |
| Line Coding Format | 4096 QAM |
| Frequency Band | 2.4 GHz, 5 GHz, 6 GHz, 320 MHz |
| Features | WMM support, UEFI support, Wi-Fi Direct, Wi-Fi Miracast ready, 802.1x authentication, 2x2 MU-MIMO technology, WMM Power Save, Wi-Fi Agile Multiband, wireless radio enable/disable, MLO, MRU |
| Compliant Standards | IEEE 802.11, IEEE 802.11b, IEEE 802.11a, IEEE 802.11d, IEEE 802.11g, IEEE 802.11i, IEEE 802.11h, IEEE 802.11e, IEEE 802.11n, IEEE 802.11k, IEEE 802.11ac, IEEE 802.11w, IEEE 802.11r, IEEE 802.11u, IEEE 802.11v, IEEE 802.11ax, Wi-Fi CERTIFIED 6, Wi-Fi CERTIFIED 6E, IEEE 802.11az, IEEE 802.11be, Wi-Fi CERTIFIED 7, Bluetooth 5.4 |
| Encryption Algorithm | PEAP, WPA2, 128-bit AES-CCMP, EAP-SIM, EAP-AKA, WPA3-Enterprise, WPA3-Personal, 256-bit AES-GCMP, EAP-TLS, EAP-TTLS, MSCHAPv2 |
| Compliant Standards | UL, cUL, CB 62368-1, FIPS 140-3 |
| OS Required | Linux, Windows 10, Windows 11 |
| Width | 0.242 cm |
| Depth | 3 cm |
| Height | 2.2 cm |
| Weight | 3.06 g |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 50 - 90% RH (non-condensing) |
