Zebra ZD500 - Label printer - direct thermal / thermal transfer - Roll (10.8cm) - 300 dpi - up to 102 mm / sec - parallel, USB 2.0, LAN, serial, Wi-Fi(n), Bluetooth 3.0 - cutter
images are for illustrative purposes only
New
Article: 1112004 Intrastat: 84433210 SKU: ZD50043-T2EC00FZ Barcode: ZD50043-T2EC0
Pricing and stock details are available to registered users only.
| Printer Type | Label printer - direct thermal / thermal transfer - monochrome |
| Localisation | United Kingdom, Europe |
| Print Speed | Up to 102 mm/sec - B/W - 300 dpi |
| Built-in Devices | Status LCD |
| Connectivity Technology | Wireless |
| Interface | Parallel, USB 2.0, LAN, serial, Wi-Fi(n), Bluetooth 3.0 |
| Max Resolution (B&W) | 300 dpi |
| Language Simulation | ZPL, ZPL II, ZBI |
| Features | Realtime clock, adjustable gap sensor |
| Cutter | Yes |
| Fonts Included | 16 x bitmapped ¦ 2 x scalable ¦ 2 x barcode |
| Barcodes | Code 93, Industrial 2 of 5, Code 39, Code 49, CODABLOCK, GS1 DataBar, QR code, MaxiCode, Aztec code, LOGMARS, EAN/JAN-8, EAN/JAN-13, UPC-A, UPC-E, MicroPDF417, Codabar, Code 128, Code 11, Interleaved 2 of 5, Postnet, PDF417, Data Matrix, Plessey, EAN-14, Standard 2 of 5 |
| RAM Installed (Max) | 128 MB |
| Technology / Form Factor | SDRAM |
| Flash Memory | 256 MB |
| Media Type | Continuous forms, receipt paper, fanfold paper, continuous paper labels, tag labels, die cut labels |
| Max Media Size | Roll (10.8cm) |
| Min Media Size (Custom) | 19 mm |
| Max Media Size (Custom) | 108 mm |
| Media Sizes | Roll (1.9 cm), Roll (10.8cm) |
| Max Printing Width | 104 mm |
| Max Printing Length | 990 mm |
| Media Thickness Range | 0.08 mm - 0.31 mm |
| Roll Maximum Outer Diameter | 127 mm |
| Roll Core Diameter | 76 mm, 12.7 mm, 37.1 mm, 25 mm, 35 mm |
| Media Feeders | 1 x manual - 1 roll - Roll (10.8cm) |
| Networking | Print server |
| Connections | 1 x RS-232 - 9 pin D-Sub (DB-9) ¦ 1 x USB 2.0 - 4 pin USB Type B ¦ 1 x parallel - 36 PIN Centronics ¦ 1 x LAN - RJ-45 |
| Cables Included | 1 x USB cable |
| Compatible with Windows 7 | "Compatible with Windows 7" software and devices carry Microsoft’s assurance that these products have passed tests for compatibility and reliability with 32-bit and 64-bit Windows 7. |
| Compliant Standards | TUV, VCCI, C-Tick, EN55022, EN55024, FCC Part 15 B, CCC, UL 60950-1, NRTL, EN 61000-3, CSA C22.2 No. 60950-1-07 + A1, EN61000-3-2:2006, IEC 60950-1:2005 (ed.2)+A1:2009, EN 60950-1:2006+A11:2009+A1:2010+A12:2011 |
| Power Device | Power supply |
| Voltage Required | AC 120/230 V |
| Frequency Required | 50/60 Hz |
| Power Factor Correction | Yes |
| Software Included | Drivers & Utilities, ZebraDesigner |
| ENERGY STAR | Yes |
| Min Operating Temperature | 4.4 °C |
| Max Operating Temperature | 41 °C |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| Width | 19.3 cm |
| Depth | 25.4 cm |
| Height | 19.1 cm |
| Weight | 2.2 kg |
