TSC TDM-30, 8 dots/mm (203 dpi), USB, BT, NFC

  • TSC TDM-30, 8 dots/mm (203 dpi), USB, BT, NFC
  • TSC TDM-30, 8 dots/mm (203 dpi), USB, BT, NFC
  • TSC TDM-30, 8 dots/mm (203 dpi), USB, BT, NFC
images are for illustrative purposes only

New

Article: 1672185 Intrastat: 84433210 SKU: 99-083A401-0012
Pricing and stock details are available to registered users only.
 Add to compare
Print technologyDirect thermal
TypeMobile printer
ColourNo
Printing media thickness60 - 160 µm
Maximum roll diameter4 cm
Supported paper width80 mm
Maximum printing width7.2 cm
Maximum media length2.79 m
Connectivity technologyWired & Wireless
USB portYes
USB 2.0 ports quantity1
BluetoothYes
Bluetooth version4.2
Standard interfacesBluetooth, USB 2.0
Ethernet LANNo
Wi-FiYes
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Built-in barcodes1D, 2D, AZTECCODE, Code 128 (A/B/C), Code 39, Code 93, EAN128, EAN13, EAN8, MaxiCode, QR Code, UPC-A, UPC-E
Page description languagesCPCL-native, DPL, EPL2, ESC/POS, ZPL II
Storage mediaFlash
Flash memory16 MB
RAM capacity0.032 GB
CertificationRoHS, WEEE, REACH
Product colourBlack
Built-in displayNo
Power source typeBattery
Battery technologyLithium-Ion (Li-Ion)
Battery voltage7.4 V
Battery capacity3080 mAh
Operating temperature (T-T)-15 - 50 °C
Storage temperature (T-T)-30 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)10 - 90%
Windows operating systems supportedYes
Mac compatibilityYes
Mac operating systems supportedYes
Mobile operating systems supportedAndroid, iOS
Width105 mm
Depth49.5 mm
Height116 mm
Weight375 g
Quick start guideYes
AC adapter includedYes
Harmonized System (HS) code84433210
LED indicatorsStatus
International Protection (IP) codeIP42
RechargeableYes
Media types supportedReflective sensor model: receipt paper, bline receipt paper (black mark in printing side) & selected label, Transmissive sensor model: receipt paper, bline receipt paper (black mark in printing side or backside) & label with gap
Storage media typeFlash
